Power Output |
100W RMS into 8 Ohms @ <1%THD+N, 155W RMS into 4 Ohms @ 1kHz <1%THD+N |
Amplification |
Class-A/B |
DAC |
ES9018K2M |
Preamp Mode |
Yes |
Frequency Response |
<3Hz – >40kHz +/-1dB |
Toroidal Transformer |
Yes |
Bi-wiring possible |
Yes |
Analogue RCA Inputs |
3 pairs |
Balanced XLR Input |
1 pair |
S/PDIF TOSLINK Input |
1 |
S/PDIF Coaxial Input |
1 |
Asynchronous USB Input |
USB Type B conforming to USB Audio Class 1 or USB Audio Class 2 (user selectable) |
Bluetooth |
5.0 aptX HD |
HDMI ARC Input |
1 (eARC compatible) |
Preamp Output |
RCA pre-out |
Headphone Output |
Yes |
Subwoofer Output |
1 x RCA |
Speaker Outputs |
Yes |
S/PDIF TOSLink Optical |
TOSLINK: 16/24-bit 32-96kHz |
S/PDIF Coaxial |
Coax SPDIF: 16/24-bit 32-192kHz |
HDMI eARC |
PCM up to 24bit/192kHz |
USB Audio |
USB Audio Class 1: Up to 24-bit 96kHz (asynchronous) | USB Audio Class 2: Up to 24-bit 384kHz (asynchronous) and up to DSD-256 |
Bluetooth |
5.0 A2DP/AVRCP supporting SBC, aptX and aptX HD codecs |
RS232 Control |
Yes |
THD (Unweighted) |
<0.002% 1kHz at 80% of rated power (8 Ohms) | <0.02% 20Hz – 20kHz at 80% of rated power |
S/N Ratio (REF 1W) |
>91 dB |
Crosstalk @1kHz |
>90 |
Input Sensitivity |
Input A2-A4 (unbalanced) 395mV RMS |
Input Impedances |
Input A1 (balanced) 100 kOhm Input A2-A4 (unbalanced) 45 kOhm |
Power Amp Damping Factor |
>160 at 1kHz |
Subwoofer Output |
1 x RCA |
Max Power Consumption |
1200w |
Standby Power Consumption |
<0.5W |
Dimensions (W x H x D) |
115 x 430 x 341mm (4.5 x 16.9 x 13.4”) |
Weight |
12.8kg (28.2Lbs) |
In the box |
Power cords, Remote control, Welcome letter, Registration Card, Safety guide |
